BODY FRONT END 9R–11
DAEWOO M-150 BL2
D19C544A
11. Remove the bolts along the top of the fender.
a. Bolt.
12. Remove the fender.
b. Fender.
D19C527A
Installation Procedure
1. Install the fender.
Notice: Dissimilar metals in direct contact with each
other may corrode rapidly. Make sure to use the correct
fasteners to prevent premature corrosion.
2. Install the bolts along the top of the fender.
D19C545A
3. Install the front bumper spacer.
4. Install the cowl vent grille.
5. Raise and suitably support the vehicle.
6. Install the bolts under the fender.
7. Install the screws on the side of the front bumper
fascia.
8. Open the front door Install the bolt on the A–pillar.
9. Install the bolt at the base of the fender.
10. Install the wheelhouse splash shield with the
screws.
11. Lower the vehicle.
