9S –4 BODY REAR END
DAEWOO M-150 BL2
D109C549
3. Pry off the lower B–pillar trim panel. Refer to Section
9G, Interior Trim.
4. Pry off the rear rocker trim panel. Refer to Section to
9G, Interior Trim.
5. Pry off the luggage compartment wheelhouse trim
panel. Refer to Section to 9G, Interior Trim.
6. Remove the lock striker of the fuel filler.
D Remove the lock striker by turning it rectangularly.
a. Lock striker
D19C550B
7. Remove the fuel filler door remote cable.
D Remove the cable retaining strip.
D Disconnect the fuel filler door remote cable (1).
D19C550C
Installation Procedure
1. Connect the fuel filler door remote cable to the fuel
filler door.
2. Retain the cable with the strip.
D19C549A
3. Install the lock striker of the fuel filler.
4. Install the luggage compartment wheelhouse trim
panel. Refer to Section 9G, Interior Trim.
5. Install the rear rocker trim panel. Refer to Section 9G,
Interior Trim.
6. Install the lower B–pillar trim panel. Refer to Section
9G, Interior Trim.
