ENGINE CONTROLS 1F–19
DAEWOO M-150 BL2
Euro On-Board Diagnostic (EOBD) System Check
Step Action Value(s) Yes No
1
1. Turn the ignition ON with the engine OFF.
2. Observe the Malfunction Indicator Lamp (MIL).
Is the MIL on?
–
Go to Step 2
Go to “No
Malfunction
Indicator
Lamp”
2
1. Turn the ignition OFF.
2. Install the scan tool.
3. Turn the ignition ON.
4. Attempt to display the Engine Control Module
(ECM) engine data with the scan tool.
Does the scan tool display the ECM engine data?
–
Go to Step 3 Go to Step 8
3
1. Using the scan tool output test function, select the
MIL lamp control and command the MIL off.
2. Observe the MIL.
Does the MIL turn off?
–
Go to Step 4
Go to
“Malfunction
Indicator Lamp
on Steady”
4
Attempt to start the engine.
Does the engine start and continue to run?
–
Go to Step 5
Go to “Engine
Cranks But
Will Not Run”
5
Select DISPLAY DTC with the scan tool.
Are any Diagnostic Trouble Codes stored?
–
Go to Step 6 Go to Step 7
6
Check the display for DTCs P0107, P0108, P0113,
P0118, P0122, P0123, P0172, P1392.
Are two or more of the following DTCs stored?
–
Go to “Multiple
ECM
Information
Sensor DTCs
Set”
Go to
applicable DTC
table
7
Compare the ECM data values displayed on the
scan tool to the typical engine scan data values.
Are the displayed values normal or close to the
typical values?
–
Go to “ECM
Output
Diagnosis”
Go to indicated
component
system check
8
1. Turn the ignition OFF and disconnect the ECM.
2. Turn the ignition ON with the engine OFF.
3. Check the serial data circuit for an open, short to
ground, or short to voltage. Also check the Data
Link Connector (DLC) ignition feed circuit for an
open or short to ground, and check the DLC
ground circuits for an open.
Is a problem found?
–
Go to Step 9 Go to Step 10
9
Repair the open, short to ground, or short to voltage
in the serial data circuit or the DLC ignition feed
circuit.
Is the repair complete?
–
System OK
–
10
1. Attempt to reprogram the ECM.
2. Attempt to display the ECM data with the scan
tool.
Does the scan tool display ECM engine data?
–
Go to Step 2 Go to Step 11
11
Replace the ECM.
Is the repair complete?
–
System OK
–
