ENGINE CONTROLS 1F–27
DAEWOO M-150 BL2
Engine Cranks But Will Not Run (Cont’d)
Step Action Value(s) Yes No
21
1. Check for any damages or poor connection in
ignition wires and repair as needed.
2. Connect the Ei system ignition coil connector and
ECM connector.
3. Check for the presence of spark from all of the
ignition wires.
Is the spark present from all of the ignition wires?
–
Go to Step 2 Go to Step 22
22
Replace ECM
Is the repair complete?
–
Go to Step 2
–
23
1. Turn the ignition OFF.
2. Connect a fuel pressure gauge.
3. Crank the engine.
Is any fuel pressure present?
–
Go to Step 26 Go to Step 24
24
1. Turn the ignition OFF.
2. Disconnect the electrical connector at the fuel
pump.
3. Connect a test light between the fuel pump
terminals 2 and 3.
4. Turn the ignition ON.
5. With the ignition ON, the test light should light for
the time specified.
Is the test light on? 2 sec. Go to Step 25 Go to Step 32
25
Replace the fuel pump.
Is the repair complete?
–
Go to Step 2
–
26
Is the fuel pressure within the value specified?
380 kPa
(55 psi) Go to Step 27 Go to Step 29
27
Check the fuel for contamination.
Is the fuel contaminated?
–
Go to Step 28 Go to Step 41
28
1. Remove the contaminated fuel from the fuel tank.
2. Clean the fuel tank as needed.
Is the repair complete?
–
Go to Step 2
–
29
1. Check the fuel filter for restriction.
2. Inspect the fuel lines for kinks and restrictions.
3. Repair or replace as needed.
4. Measure the fuel pressure.
Is the fuel pressure within the value specified?
380 kPa
(55 psi)
Go to Step 2 Go to Step 30
30
1. Disconnect vacuum line from the fuel pressure
regulator.
2. Inspect the vacuum line for the presence of fuel.
3. Inspect the fuel pressure regulator vacuum port
for the presence of fuel.
Is any fuel present?
–
Go to Step 31 Go to Step 32
31
Replace the fuel pressure regulator.
Is the repair complete?
–
Go to Step 2
–
32
1. Remove the fuel pump assembly from the fuel
tank.
2. Inspect the fuel pump sender and the fuel
coupling hoses for a restriction.
3. Inspect the in-tank fuel filter for restriction.
Is the problem found?
–
Go to Step 33 Go to Step 25
