ENGINE CONTROLS 1F–41
DAEWOO M-150 BL2
Manifold Absolute Pressure Check
Step Action Value(s) Yes No
1
1. Turn the ignition OFF.
2. Connect a scan tool to the Data Link Connector
(DLC).
3. Turn the ignition ON.
4. Compare the Manifold Absolute Pressure (MAP)
sensor voltage reading from scanner with that
from known good vehicle.
Is the difference in the two voltage reading less than
the value specified?
0.4 V Go to Step 2 Go to Step 5
2
1. Turn the ignition OFF.
2. Connect a scan tool to the DLC.
3. Disconnect the MAP sensor vacuum line.
4. Connect a hand vacuum pump to the Map sensor.
5. Turn the ignition ON.
6. Note the MAP sensor voltage.
7. Apply 34kPa (10 in. Hg) of vacuum to the Map
sensor and note the voltage change.
Is the difference in voltage readings more than the
value specified?
1.5 V System OK Go to Step 3
3
Inspect the MAP sensor connector terminals.
Is the problem found.
–
Go to Step 4 Go to Step 5
4
Repair the MAP sensor connector terminals as
needed.
Is the repair complete?
–
System OK
–
5
Replace the MAP sensor.
Is the repair complete?
–
System OK
–
