ENGINE CONTROLS 1F–77
DAEWOO M-150 BL2
DTC P0122 – Throttle Position Sensor Low Voltage
Step Action Value(s) Yes No
1
Perform an On-Board Diagnostic (EOBD) System
Check.
Was the check performed?
–
Go to Step 2
Go to
“On-Board
Diagnostic
System Check”
2
1. Install a scan tool to the Data Link Connector
(DLC).
2. Turn the ignition ON.
Is the Throttle Position (TP) sensor voltage below
the specified value? 0.20 V Go to Step 4 Go to Step 3
3
1. Turn the ignition ON.
2. Review the Freeze Frame data and note the
parameters.
3. Operate the vehicle within the Freeze Frame
conditions and Conditions for Setting the DTC as
noted.
Is the TP sensor voltage below the specified value? 0.20 V Go to Step 4 Go to Step 12
4
1. Turn the ignition OFF.
2. Disconnect the TP sensor connector.
3. Turn the ignition ON.
4. Jump the 5 volt reference circuit terminal B and
the TP signal circuit terminal C at the TP sensor
connector.
Is the TP sensor voltage over the specified value? 4.0 V Go to Step 10 Go to Step 5
5
Connect a test light between B+ and the TP sensor
signal circuit terminal C.
Is the TP sensor voltage greater than the specified
value? 4.0 V Go to Step 6 Go to Step 8
6
Check the TP sensor 5 volt reference circuit for an
open or short to ground and repair as needed.
Is the repair complete?
–
Go to Step 12 Go to Step 7
7
Check the 5 volt reference circuit for a poor
connection at terminal 75 of the Engine Control
Module (ECM) and repair as needed.
Is the repair complete?
–
Go to Step 12 Go to Step 11
8
Check the TP sensor signal circuit between terminal
C of the TP sensor and terminal 44 of the ECM for
an open or a short to ground and repair as needed.
Is the repair complete?
–
Go to Step 12 Go to Step 9
9
Check the TP sensor signal circuit, terminal 44 of
the ECM for a poor connection and repair as
needed.
Is the repair complete?
–
Go to Step 12 Go to Step 11
10
Replace the throttle body assembly.
Is the action complete?
–
Go to Step 12
–
11
1. Turn the ignition switch OFF.
2. Replace the ECM.
Is the action complete?
–
Go to Step 12
–
