1F–116 ENGINE CONTROLS
DAEWOO M-150 BL2
DTC P1230 – Fuel Pump Relay Low Voltage (Cont’d)
Step Action Value(s) Yes No
11
1. Repair the wire between the fuel pump relay
connector terminal 66 and the ignition key ON
(IGN1).
2. Install the fuel pump relay.
3. Turn the ignition OFF for 10 seconds.
4. Clear any DTCs from ECM.
5. Turn the ignition switch to ON.
Does the fuel pump operate? 2.55 seconds System OK Go to Step 13
12
1. Repair the wire between the fuel pump relay
connector terminal 85 and the ECM connector
terminal 10.
2. Install the fuel pump relay.
3. Turn the ignition OFF for 10 seconds.
4. Clear any DTCs from ECM.
5. Turn the ignition switch to ON.
Does the fuel pump operate? 2.55 seconds System OK Go to Step 13
13
1. Replace the ECM.
2. Turn the ignition OFF for 10 seconds.
3. Clear any DTCs from ECM.
4. Turn the ignition switch to ON.
Does the fuel pump operate? 2.55 seconds System OK Go to Step 14
14
1. Using the scan tool, clear the DTCs.
2. Start the engine and idle at normal operating
temperature.
3. Operate the vehicle within the conditions for
setting this DTC ad specified in the supporting
text.
Does the scan tool indicate that this diagnostic has
run and passed?
–
Go to Step 15 Go to Step 2
15
Check if any additional DTCs are set.
Are any DTCs displayed that have not been
diagnosed?
–
Go to
applicable DTC
table
System OK
To Next Page
