ENGINE CONTROLS 1F227
DAEWOO M-150 BL2
a Freeze Frame conditions (rpm, load, vehicle speed, temperature, etc.) that .are noted. This will isolate when
the DTC failed.
DTC P0480 Low Speed Cooling Fan Relay Circuit Fault (WITHOUT A/C)
Step Action Value(s) Yes No
1
Perform an Euro On-Board Diagnostic (EOBD)
System Check.
Is the system check complete?
Go to Step 2
Go to
On-Board
Diagnostic
System Check
2
1. Turn the ignition switch to ON with the engine
OFF.
2. Install a scan tool.
3. Command the relay ON and OFF.
Does the relay turn ON and OFF when
commanded?
Go to Step 3
Go to Step 5
3
1. Turn the ignition switch to LOCK.
2. Disconnect the engine control module (ECM)
connector.
3. Turn the ignition switch to ON.
4. Using a digital voltmeter(DVM), measure the
current in low speed relay control circuit, at
terminal 39 to ground for 2 minutes.
Does the amperage measure less than the specified
value?
0.75 amps
Go to
Diagnostic
Aids Go to Step 4
4
1. Turn the ignition switch to LOCK.
2. Disconnect the relay.
3. Using a DVM, measure the resistance between
terminals 87 and 39 in the relay control circuit in
the ECM harness connector to ground.
Does the DVM display infinite resistance?
Go to Step 12 Go to Step 10
5
1. Turn the ignition switch to LOCK.
2. Disconnect the relay.
3. Connect a test light between the relay coil
terminals 30 and 87 in the relay harness
connector.
4. Turn the Turn the ignition switch to ON.
5. Using the scan tool, command the relay ON and
OFF.
Does the test light turn ON and OFF with each
commanded?
Go to Step 8 Go to Step 6
6
With the test light connected to ground, probe the
ignition feed circuit in the relay harness connector.
Does the test light illuminate?
Go to Step 7 Go to Step 11
7
1. Turn the ignition switch to LOCK.
2. Reconnect the relay.
3. Disconnect the ECM connector containing the
relay control circuit.
4. Turn the Turn the ignition switch to ON.
5. With a fused jumper wire connected to ground,
probe the relay control circuit at terminal 39 in the
ECM harness connector.
Does the relay operate?
Go to Step 9 Go to Step 10
8
Check the connections at the relay.
Is a problem found and corrected?
Go to Step 14 Go to Step 12
