FRONT SUSPENSION 2C–15
DAEWOO M-150 BL2
D16B531A
17–27 NSm
17–27 NSm
c. Crossmember left rear bolt.
d. Crossmember leftt side bolt.
D16B532A
68–83 NSm
4. Install the front damping bush to the vehicle.
Tighten
Tighten the front damping bush bolt and nut to 68–83
NSm (51–61 lb-ft).
5. Install the front under longitudinal frame. Refer to
“Stabilizer Shaft” in this section.
To Next Page
