2D –10 REAR SUSPENSION
DAEWOO M-150 BL2
D106C519
5. Remove the rear bumper stopper and rear spring up-
per seat.
a. Rear bumper stopper.
b. Rear spring upper seat.
D106C520
Installation Procedure
1. Install in the reverse order of removal.
Important: Make sure the spring diameter prior to
installing the spring. Upper spring diameter is smaller
than lower spring diameter.
Caution: Support the jack stand to the rear axle se-
curely until installing the trailing arm bolts.
D106C519
2. Install the rear bumper stopper and rear spring upper
seat.
