1D–16 ENGINE COOLING
DAEWOO M-150 BL2
9–12 NSm
9–12 NSm
D12D520A
D12D521A
Installation Procedure
1. Install the coolant pump with the new gasket.
Tighten
Tighten the bolts and the nuts to 9–12 NSm (80–106
lb-in) (a).
2. Install the rear timing belt cover.
Tighten
Tighten the bolts to 9–12 NSm (80–106 lb-in) (b).
3. Install the timing belt. Refer to Section 1B, Engine
Mechanical.
4. Connect the lower radiator hose and drain the cool-
ant. Refer to “Draining and Refilling the Cooling Sys-
tem” in this section.
5. Connect the negative battery cable.
To Next Page
