SEAT BELTS 8A–7
DAEWOO M-150 BL2
D11A502A
3. Remove the lower B–pillar trim panel. Refer to Sec-
tion 9G, Interior Trim.
4. Remove the bolt on the upper B–pillar.
D Using a flathead screwdriver, open the bolt cap (1).
D Remove the bolt (2).
D Remove the spacer and the fiber washer (3).
D28A001A
5. Remove the seat belt retractor bolts.
D Remove the floor carpet to be seen the retractor.
D Disconnect the pretensioner front seat belt con-
nector (1).
D Remove the lower retractor bolt (2).
D Remove the fiber washer (3).
D Remove the seat belt retractor.
D1AA504C
Installation Procedure
Notice: Dissimilar metals in direct contact with each
other may corrode rapidly. Make sure to use the correct
fasteners to prevent premature corrosion.
1. Install in the reverse order of removal.
2. Install the bolt on the upper B–pillar.
Tighten
Tighten the seat belt upper bolt to 30–45 NSm (22–33
lb-ft).
a. Seat belt upper bolt.
D28A002A
3. Install the seat belt retractor with the bolt.
Tighten
D Tighten the lower retractor bolt to 30–45 NSm
(22–33 lb-ft).
a. Lower retractor bolt.
b. Connect the pretensioner front seat belt con-
nector.
