ENGINE ELECTRICAL 1E–31
DAEWOO M-150 BL2
D102E748
8. Remove the stator assembly from the frame.
D Remove the remains after the welding.
D Remove the stator assembly (2).
D102E749
Inspection / Measurement
1. Inspect the rotor assembly.
D Test the rotor coil for an open circuit by using the
ohmmeter. The reading should be sufficiently low,
or the rotor must be replaced (1).
D102E750
D Test the rotor for open or short circuits. The read-
ing should be 2.6 to 2.8 ohms, or the rotor should
be replaced (2).
D Test the rotor for open or ground circuits by using
the ohmmeter. The reading should be sufficiently
high, or the rotor must be replaced (3).
D Inspect the fan blade for damage.
D102E751
2. Inspect the stator.
D Test the rotor for an open circuit by using the ohm-
meter. The reading should be sufficiently low, or
the stator must be replaced (1).
