8B–72 SUPPLEMENTAL INFLATABLE RESTRAINTS (SIR)
DAEWOO M-150 BL2
D1AB508A
3. Connect the passenger airbag module connector.
4. Install the glove box. Refer to Section 9E, Instrument/
Driver Information.
5. Connect the negative battery cable.
D19E573A
SENSING AND DIAGNOSTIC
MODULE (SDM)
Tool Required
DS 401 Torx Bolt Wrench.
Removal Procedure
1. Disconnect the negative battery cable.
2. Remove the floor console. Refer to Section 9G, Inte-
rior Trim.
D110B511
3. Remove the SDM.
D Disconnect the SDM electrical connector (1).
D Remove the torx bolts using a torx bolt wrench DS
401 (2).
D Remove the SDM (3).
D1AB512A
Installation Procedure
Notice: Do not install an SDM that has been dropped or
has water damage, dents, cracks, or other visible de-
fects. Attempted use of a defective SDM can result in
vehicle damage.
1. Install the SDM with the mounting torx bolts so that
the arrow on the SDM label points toward the front of
the vehicle.
Notice : Ground the wiring harness to the mounting torx
bolt (1).
Tighten
Tighten the SDM mounting torx bolts to 15 NSm (11
lb-ft).
2. Connect the SDM electrical connector.
To Next Page
