BODY WIRING SYSTEM 9A–3
DAEWOO M-150 BL2
Contents of Electrical Wiring Diagram
Position Explanation
A
– The box above the fuse box: Power supply lines
– Power supply lines: 30, 15, 15A, Ka, 58, 50
– Refer to “Circuit Identification Symbol” in this section for more details.
B
– Ef10 or F3: Fuse Number
S Ef10: Fuse No 10 in the engine room fuse box
S F3: Fuse No 3 in the passenger room fuse box
– 40A: Fuse Capacity
– Refer to “Relay Box Locator” and “Fuse Box Locator” in this section.
C
– Connector
– Connector No C202, terminal No 10
– Refer to “How to Check Terminal Number of Connect” in this section
D
– Internal circuit of component (Relay)
(Component Name, Terminal Number)
E
– Internal circuit of component (Switch)
(Terminal Number)
F
– Wiring Harness Color
– Refer to “Wire Color Chart” in this section
G
– Ground line.
– G402: Ground Position
– In case of the ground numberless, this means the body ground.
Circuit Identification Symbol
Identification Symbol Meaning
C Connector
Ef Fuse in engine room fuse box
F Fuse in passenger compartment fuse box
G Ground
To Next Page
