9E –18 INSTRUMENT/DRIVER INFORMATION
DAEWOO M-150 BL2
D109B706
8. Remove the glove box striker and bracket from the
instrument panel.
D Remove the screws (1).
D Remove the glove box striker and bracket (2).
D109B707
9. Remove the instrument panel guide from the instru-
ment panel.
D Remove the screws (1).
D Remove the instrument panel guide (2).
D109B708
10. Remove the defroster grilles and the demister grilles
from the instrument panel.
a. Defroster grille.
b. Demister grille.
D109B521
Installation Procedure
1. Install the defroster grilles and the demister grilles to
the instrument.
2. Install the instrument panel guide to the instrument
panel with the screws.
3. Install the glove box striker and the bracket to the in-
strument panel with the screws.
4. Install the cigar lighter housing to the instrument pan-
el with the screws.
5. Install the ventilation grilles to the instrument panel
with the screws.
6. Install the ventilation duct to the instrument panel with
the screws.
