Ethernet Configuration Commands 135
InMcastPkts Counted received multicast packets.
InBcastPkts Counted received broadcast packets.
OutOctets Counted transmitted octets.
OutUcastPkts Counted transmitted unicast packets.
OutMcastPkts Counted transmitted multicast packets.
OutBcastPkts Counted transmitted broadcast packets.
Alignment Errors A count of frames received that are not an integral number of octets in length
and do not pass the FCS check.
FCS Errors Counted frames received that are an integral number of octets in length but
do not pass the FCS check.
Single Collision Frames Counted frames that are involved in a single collision, and are subsequently
transmitted successfully.
Multiple Collision
Frames
A count of frames that are involved in more than one collision and are
subsequently transmitted successfully
SQE Test Errors A count of times that the SQE TEST ERROR is received. The SQE TEST
ERROR is set in accordance with the rules for verification of the SQE
detection mechanism in the PLS Carrier Sense Function as described in
IEEE Std. 802.3, 2000 Edition, section 7.2.4.6.
Deferred Transmissions A count of frames for which the first transmission attempt is delayed because
the medium is busy.
Late Collisions Counted times that a collision is detected later than one slotTime into the
transmission of a packet.
Excessive Collisions Counted frames for which transmission fails due to excessive collisions.
Internal MAC Tx Errors Counted frames for which transmission fails due to an internal MAC sublayer
transmit error.
Carrier Sense Errors The number of times that the carrier sense condition was lost or never
asserted when attempting to transmit a frame.
Oversize Packets Counted frames received that exceed the maximum permitted frame size.
Internal MAC Rx Errors Counted frames for which reception fails due to an internal MAC sublayer
receive error.
