Chapter 8
| Authentication Commands
802.1X Port Authentication
– 290 –
â—† Authenticator PAE State Machine
â–
State – Current state (including initialize, disconnected,
connecting,
authenticating, authenticated, aborting,
held, force_authorized,
force_unauthorized).
â–
Reauth Count– Number of times connecting state is re-entered.
â–
Current Identifier– The integer (0-255) used by the Authenticator to identify
the current authentication session.
â—† Backend State Machine
â–
State – Current state (including request, response, success, fail, timeout,
idle, initialize).
â–
Request Count– Number of EAP Request packets sent to the Supplicant
without receiving a response.
â–
Identifier (Server)– Identifier carried in the most recent EAP Success, Failure
or Request packet received from the Authentication Server.
â—† Reauthentication State Machine
State – Current state (including initialize, reauthenticate).
Example
Console#show dot1x
Global 802.1X Parameters
System Auth Control : Enabled
Authenticator Parameters:
EAPOL Pass Through : Disabled
Supplicant Parameters:
Identity Profile Username : steve
802.1X Port Summary
Port Type Operation Mode Control Mode Authorized
-------- ------------- -------------- ------------------ ----------
Eth 1/ 1 Disabled Single-Host Force-Authorized Yes
Eth 1/ 2 Disabled Single-Host Force-Authorized Yes
.
.
.
Eth 1/27 Disabled Single-Host Force-Authorized Yes
Eth 1/28 Enabled Single-Host Auto Yes
802.1X Port Details
802.1X Authenticator is enabled on port 1/1
802.1X Supplicant is disabled on port 1/1
.
.
.
802.1X Authenticator is enabled on port 28
Reauthentication : Enabled
Reauth Period : 3600
Quiet Period : 60
TX Period : 30
Supplicant Timeout : 30
Server Timeout : 10
