Chapter 12
| Security Measures
Configuring 802.1X Port Authentication
– 363 –
Displaying
802.1X Statistics
Use the Security > Port Authentication (Show Statistics) page to display statistics for
dot1x protocol exchanges for any port.
Parameters
These parameters are displayed:
Table 21: 802.1X Statistics
Parameter Description
Authenticator
Rx EAPOL Start The number of EAPOL Start frames that have been received by this
Authenticator.
Rx EAPOL Logoff The number of EAPOL Logoff frames that have been received by
this Authenticator.
Rx EAPOL Invalid The number of EAPOL frames that have been received by this
Authenticator in which the frame type is not recognized.
Rx EAPOL Total The number of valid EAPOL frames of any type that have been
received by this Authenticator.
Rx Last EAPOLVer The protocol version number carried in the most recent EAPOL
frame received by this Authenticator.
Rx Last EAPOLSrc The source MAC address carried in the most recent EAPOL frame
received by this Authenticator.
Rx EAP Resp/Id The number of EAP Resp/Id frames that have been received by this
Authenticator.
Rx EAP Resp/Oth The number of valid EAP Response frames (other than Resp/Id
frames) that have been received by this Authenticator.
Rx EAP LenError The number of EAPOL frames that have been received by this
Authenticator in which the Packet Body Length field is invalid.
Tx EAP Req/Id The number of EAP Req/Id frames that have been transmitted by
this Authenticator.
Tx EAP Req/Oth The number of EAP Request frames (other than Rq/Id frames) that
have been transmitted by this Authenticator.
Tx EAPOL Total The number of EAPOL frames of any type that have been
transmitted by this Authenticator.
Supplicant
Rx EAPOL Invalid The number of EAPOL frames that have been received by this
Supplicant in which the frame type is not recognized.
Rx EAPOL Total The number of valid EAPOL frames of any type that have been
received by this Supplicant.
Rx Last EAPOLVer The protocol version number carried in the most recent EAPOL
frame received by this Supplicant.
Rx Last EAPOLSrc The source MAC address carried in the most recent EAPOL frame
received by this Supplicant.
Rx EAP Resp/Id The number of EAP Resp/Id frames that have been received by this
Supplicant.
Rx EAP Resp/Oth The number of valid EAP Response frames (other than Resp/Id
frames) that have been received by this Supplicant.
