Edge-Core ECS4620-28T - Figure 262: Creating an SNMP Group

Chapter 13 | Basic Administration Protocols
Simple Network Management Protocol
– 432 –
Web Interface
To configure an SNMP group:
1. Click Administration, SNMP.
2. Select Configure Group from the Step list.
3. Select Add from the Action list.
4. Enter a group name, assign a security model and level, and then select read,
write, and notify views.
5. Click Apply
Figure 262: Creating an SNMP Group
To show SNMP groups:
1. Click Administration, SNMP.
2. Select Configure Group from the Step list.
3. Select Show from the Action list.
