Chapter 2
| Using the Web Interface
Navigating the Web Browser Interface
– 57 –
switches. Other than the difference in port types, and support for PoE (ECS4620-
28P/52P), there are no other significant differences. Therefore nearly all of the
screen display examples are based on the ECS4620-28T. The panel graphics for all
switch types are shown on the following page.
N
OTE
:
You can open a connection to the vendor’s web site by clicking on the
Edge-core logo.
Configuration Options Configurable parameters have a dialog box or a drop-down list. Once a
configuration change has been made on a page, be sure to click on the Apply
button to confirm the new setting. The following table summarizes the web page
configuration buttons.
Table 3: Web Page Configuration Buttons
Button Action
Apply Sets specified values to the system.
Revert Cancels specified values and restores current
values prior to pressing “Apply.”
Displays help for the selected page.
Refreshes the current page.
Displays the site map.
Logs out of the management interface.
Sends mail to the vendor.
Links to the vendor’s web site.
