Chapter 19
| Unicast Routing
Configuring the Open Shortest Path First Protocol (Version 2)
– 742 –
To configure interface settings for a specific area assigned to a VLAN:
1. Click Routing Protocol, OSPF, Interface.
2. Select Configure by Address from the Action list.
3. Specify the VLAN ID, enter the address assigned to an area, and configure the
required interface settings.
4. Click Apply.
Figure 506: Configuring Settings for a Specific Area Assigned to a VLAN
To show the configuration settings for OSPF interfaces:
1. Click Routing Protocol, OSPF, Interface.
2. Select Show from the Action list.
3. Select the VLAN ID.
