Chapter 13
| Basic Administration Protocols
Connectivity Fault Management
– 511 –
â—† Target
â–
MEP ID – The identifier of a remote MEP that is the target of a loopback
message. (Range: 1-8191)
â–
MAC Address – MAC address of a remote MEP that is the target of a
loopback message. This address can be entered in either of the following
formats: xx-xx-xx-xx-xx-xx or xxxxxxxxxxxx
◆ Count – The number of times the loopback message is sent. (Range: 1-1024)
◆ Packet Size – The size of the loopback message. (Range: 64-1518 bytes;
Default: 64 bytes)
Web Interface
To transmit loopback messages:
1. Click Administration, CFM.
2. Select Transmit Loopback from the Step list.
3. Select an entry from MD Index and MA Index.
4. Specify the source MEP, the target MEP using either its MEP identifier or MAC
address, set the number of times the loopback message is to be sent.
5. Click Apply.
Figure 317: Transmitting Loopback Messages
