Chapter 15
| IP Configuration
Setting the Switch’s IP Address (IP Version 6)
– 633 –
nodes. The interface-local multicast address is only used for loopback
transmission of multicast traffic. Link-local multicast addresses cover the same
types as used by link-local unicast addresses, including all nodes (FF02::1), all
routers (FF02::2), and solicited nodes (FF02::1:FFXX:XXXX) as described below.
A node is also required to compute and join the associated solicited-node
multicast addresses for every unicast and anycast address it is assigned. IPv6
addresses that differ only in the high-order bits, e.g. due to multiple high-order
prefixes associated with different aggregations, will map to the same solicited-
node address, thereby reducing the number of multicast addresses a node
must join. In this example, FF02::1:FF90:0/104 is the solicited-node multicast
address which is formed by taking the low-order 24 bits of the address and
appending those bits to the prefix.
Note that the solicited-node multicast address (link-local scope FF02) is used to
resolve the MAC addresses for neighbor nodes since IPv6 does not support the
broadcast method used by the Address Resolution Protocol in IPv4.
These additional addresses are displayed by the “show ip interface” command
described in the CLI Reference Guide.
◆ Configuration Mode – Indicates if this address was automatically generated or
manually configured.
Web Interface
To show the configured IPv6 addresses:
1. Click IP, IPv6 Configuration.
2. Select Show IPv6 Address from the Action list.
3. Select a VLAN from the list.
Figure 407: Showing Configured IPv6 Addresses
