Chapter 12
| Security Measures
Access Control Lists
– 331 –
Web Interface
To add rules to a Standard IPv6 ACL:
1. Click Security, ACL.
2. Select Configure ACL from the Step list.
3. Select Add Rule from the Action list.
4. Select IPv6 Standard from the Type list.
5. Select the name of an ACL from the Name list.
6. Specify the action (i.e., Permit or Deny).
7. Select the source address type (Any, Host, or IPv6-prefix).
8. If you select “Host,” enter a specific address. If you select “IPv6-prefix,” enter a
subnet address and the prefix length.
9. Click Apply.
Figure 202: Configuring a Standard IPv6 ACL
Configuring an
Extended IPv6 ACL
Use the Security > ACL (Configure ACL - Add Rule - IPv6 Extended) page to
configure an Extended IPv6 ACL.
Parameters
These parameters are displayed:
◆ Type – Selects the type of ACLs to show in the Name list.
◆ Name – Shows the names of ACLs matching the selected type.
