Chapter 12
| Security Measures
IPv4 Source Guard
– 372 –
Web Interface
To configure static bindings for IP Source Guard:
1. Click Security, IP Source Guard, Static Configuration.
2. Select Configure ACL Table or Configure MAC Table from the Step list.
3. Select Add from the Action list.
4. Enter the required bindings for each port.
5. Click Apply
Figure 226: Configuring Static Bindings for IPv4 Source Guard
To display static bindings for IP Source Guard:
1. Click Security, IP Source Guard, Static Binding.
2. Select Configure ACL Table or Configure MAC Table from the Step list.
3. Select Show from the Action list.
Figure 227: Displaying Static Bindings for IPv4 Source Guard
