– 17 –
2 Installation Overview
This chapter includes these sections:
◆ “Package Contents” on page 17
◆ “Switch Installation Tasks” on page 18
Package Contents
After unpacking the switch, check the contents to be sure you have received all the
components.
◆ ECS4620-28T, ECS4620-28T-DC, ECS4620-28P, ECS4620-28F, ECS4620-28F-DC,
ECS4620-52T, or ECS4620-52P Switch
◆ AC Power Cord—either US, Continental Europe or UK
◆ DC connector plug (ECS4620-28T-DC and ECS4620-28F-DC only)
◆ Rack Mounting Kit — includes two brackets and eight screws
◆ Four adhesive foot pads
◆ Console cable — RJ-45 to DB-9
◆ Documentation — Quick Start Guide and Regulatory and Safety Information
◆ Documentation CD — includes Installation Guide, Web Management Guide, and
CLI Reference Guide.
