Chapter 19
| Unicast Routing
Configuring the Open Shortest Path First Protocol (Version 2)
– 737 –
imported into the routing table, and then configure one or more summary
addresses to reduce the size of the routing table and consolidate these external
routes for advertising into the local domain.
â—† To summarize routes sent between OSPF areas, use the Area Range
Configuration screen (page 732).
â—† This router supports up 20 Type-5 summary routes.
Parameters
These parameters are displayed:
◆ Process ID – Process ID as configured in the Network Area configuration screen
(see page 717).
◆ IP Address – Summary address covering a range of addresses.
◆ Netmask – Network mask for the summary route.
Web Interface
To configure the router to summarize external routing information:
1. Click Routing Protocol, OSPF, Summary Address.
2. Select Add from the Action list.
3. Specify the process ID, the base address and network mask.
4. Click Apply.
Figure 503: Summarizing External Routes
To show the summary addresses for external routes:
1. Click Routing Protocol, OSPF, Summary Address.
2. Select Show from the Action list.
3. Select the process ID.
