Edge-Core ECS4620-28T - Figure 220: Configuring Interface Settings for 802.1 X Port Authenticator

Chapter 12 | Security Measures
Configuring 802.1X Port Authentication
– 360 –
Web Interface
To configure port authenticator settings for 802.1X:
1. Click Security, Port Authentication.
2. Select Configure Interface from the Step list.
3. Click Authenticator.
4. Modify the authentication settings for each port as required.
5. Click Apply
Figure 220: Configuring Interface Settings for 802.1X Port Authenticator
