Chapter 13
| Basic Administration Protocols
Configuring Event Logging
– 391 –
◆ RAM Level – Limits log messages saved to the switch’s temporary RAM
memory for all levels up to the specified level. For example, if level 7 is
specified, all messages from level 0 to level 7 will be logged to RAM.
(Range: 0-7, Default: 7)
Note:
The Flash Level must be equal to or less than the RAM Level.
Note:
All log messages are retained in RAM and Flash after a warm restart (i.e.,
power is reset through the command interface).
Note:
All log messages are retained in Flash and purged from RAM after a cold
restart (i.e., power is turned off and then on through the power source).
Web Interface
To configure the logging of error messages to system memory:
1. Click Administration, Log, System.
2. Select Configure Global from the Step list.
3. Enable or disable system logging, set the level of event messages to be logged
to flash memory and RAM.
4. Click Apply.
Figure 237: Configuring Settings for System Memory Logs
To show the error messages logged to system or flash memory:
1. Click Administration, Log, System.
2. Select Show System Logs from the Step list.
3. Click RAM to display log messages stored in system memory, or Flash to display
messages stored in flash memory.
This page allows you to scroll through the logged system and event messages.
The switch can store up to 2048 log entries in temporary random access
