– 793 –
A Software Specifications
Software Features
Management
Authentication
Local, RADIUS, TACACS+, Port Authentication (802.1X), HTTPS, SSH, Port Security, IP Filter
General Security
Measures
Access Control Lists (512 rules), Port Authentication (802.1X), MAC Authentication,
Port Security, DHCP Snooping, IP Source Guard
Port Configuration 1000BASE-T: 10/100 Mbps at half/full duplex, 1000 Mbps at full duplex
1000BASE-SX/LX/ZX: 1000 Mbps at full duplex (SFP
25
, SFP+)
10GBASE-SR/LR/ER: 10 Gbps at full duplex (SFP+)
Flow Control Full Duplex: IEEE 802.3-2005
Half Duplex: Back pressure
Storm Control Broadcast, multicast, or unknown unicast traffic throttled above a critical threshold
Port Mirroring 10 sessions, one or more source ports to one destination port
Rate Limits Input/Output Limits
Range configured per port
Port Trunking Static trunks (Cisco EtherChannel compliant)
Dynamic trunks (Link Aggregation Control Protocol)
25. ECS4620-28F, ECS4620-28F-DC
