Chapter 13
| Basic Administration Protocols
OAM Configuration
– 524 –
â–
EXCESS_LEV – The number of different MD levels at which MIPs are to be
created on this port exceeds the bridge's capabilities.
â–
OVERLAP_LEV – A MEP is created for one VID at one maintenance level, but
a MEP is configured on another VID at an equivalent or higher level,
exceeding the bridge's capabilities.
◆ MA Name – The maintenance association for this entry.
Web Interface
To show CFM continuity check errors:
1. Click Administration, CFM.
2. Select Show Information from the Step list.
3. Select Show Continuity Check Error from the Action list.
Figure 326: Showing Continuity Check Errors
OAM Configuration
The switch provides OAM (Operation, Administration, and Maintenance) remote
management tools required to monitor and maintain the links to subscriber CPEs
(Customer Premise Equipment). This section describes functions including
enabling OAM for selected ports, loopback testing, and displaying remote device
information.
Enabling OAM
on Local Ports
Use the Administration > OAM > Interface page to enable OAM functionality on the
selected port. Not all CPEs support operation and maintenance functions, so OAM
is therefore disabled by default. If a CPE supports OAM, this functionality must first
be enabled on the connected port to gain access to the configuration functions
provided under the OAM menu.
Parameters
These parameters are displayed:
◆ Port – Port identifier. (Range: 1-28/52)
