Chapter 13
| Basic Administration Protocols
Connectivity Fault Management
– 518 –
Displaying
Remote MEPs
Use the Administration > CFM > Show Information (Show Remote MEP) page to
show MEPs located on other devices which have been discovered through
continuity check messages, or statically configured in the MEP database and
verified through cross-check messages.
Parameters
These parameters are displayed:
◆ MEP ID – Maintenance end point identifier.
◆ MA Name – Maintenance association name.
◆ Level – Authorized maintenance level for this domain.
◆ Primary VLAN – Service VLAN ID.
◆ MEP Up – Indicates whether or not this MEP is functioning normally.
◆ Remote MAC Address – MAC address of the remote maintenance point. (If a
CCM for the specified remote MEP has never been received or the remote MEP
record times out, the address will be set to the initial value of all Fs.)
Web Interface
To show information for remote MEPs:
1. Click Administration, CFM.
2. Select Show Information from the Step list.
3. Select Show Remote MEP from the Action list.
Figure 322: Showing Information on Remote MEPs
