Edge-Core ECS4620-28T User Manual

Chapter 16 | IP Services
Configuring the PPPoE Intermediate Agent
– 667 –
■
PADO – PPPoE Active Discovery Offer messages.
■
PADR – PPPoE Active Discovery Request messages.
■
PADS – PPPoE Active Discovery Session-Confirmation messages.
■
PADT – PPPoE Active Discovery Terminate messages.
◆ Dropped – Dropped PPPoE active discovery messages.
■
Response from untrusted – Response from an interface which not been
configured as trusted.
■
Request towards untrusted – Request sent to an interface which not been
configured as trusted.
■
Malformed – Corrupted PPPoE message.
Web Interface
To show statistics for PPPoE IA protocol messages:
1. Click IP Service, PPPoE Intermediate Agent.
2. Select Show Statistics from the Step list.
3. Select Port or Trunk interface type.
Figure 439: Showing PPPoE Intermediate Agent Statistics
