Chapter 12
| Link Aggregation Commands
Trunk Status Display Commands
– 452 –
◆ If the actor does not receive an LACPDU from its partner before the configured
timeout expires, the partner port information will be deleted from the LACP
group.
◆ When a dynamic port-channel member leaves a port-channel, the default
timeout value will be restored on that port.
◆ When a dynamic port-channel is torn down, the configured timeout value will
be retained. When the dynamic port-channel is constructed again, that timeout
value will be used.
Example
Console(config)#interface port-channel 1
Console(config-if)#lacp timeout short
Console(config-if)#
Trunk Status Display Commands
show lacp This command displays LACP information.
Syntax
show lacp [port-channel] {counters | internal | neighbors | sys-id}
port-channel - Local identifier for a link aggregation group. (Range: 1-16)
counters - Statistics for LACP protocol messages.
internal - Configuration settings and operational state for local side.
neighbors - Configuration settings and operational state for remote side.
sys-id - Summary of system priority and MAC address for all channel
groups.
Default Setting
Port Channel: all
Command Mode
Privileged Exec
Example
Console#show lacp 1 counters
Port Channel: 1
-------------------------------------------------------------------------
Eth 1/ 2
-------------------------------------------------------------------------
LACPDUs Sent : 12
LACPDUs Received : 6
Marker Sent : 0
Marker Received : 0
LACPDUs Unknown Pkts : 0
LACPDUs Illegal Pkts : 0
.
