Chapter 12
| Link Aggregation Commands
Trunk Status Display Commands
– 455 –
Console#show lacp sysid
Port Channel System Priority System MAC Address
-------------------------------------------------------------------------
1 32768 00-30-F1-8F-2C-A7
2 32768 00-30-F1-8F-2C-A7
3 32768 00-30-F1-8F-2C-A7
4 32768 00-30-F1-8F-2C-A7
5 32768 00-30-F1-8F-2C-A7
6 32768 00-30-F1-8F-2C-A7
7 32768 00-30-F1-D4-73-A0
8 32768 00-30-F1-D4-73-A0
9 32768 00-30-F1-D4-73-A0
10 32768 00-30-F1-D4-73-A0
11 32768 00-30-F1-D4-73-A0
12 32768 00-30-F1-D4-73-A0
.
.
.
show port-channel
load-balance
This command shows the load-distribution method used on aggregated links.
Command Mode
Privileged Exec
Example
Console#show port-channel load-balance
Trunk Load Balance Mode: Destination IP address
Console#
Port Admin Priority Current administrative value of the port priority for the protocol partner.
Port Oper Priority Priority value assigned to this aggregation port by the partner.
Admin Key Current administrative value of the Key for the protocol partner.
Oper Key Current operational value of the Key for the protocol partner.
Admin State Administrative values of the partner’s state parameters. (See preceding table.)
Oper State Operational values of the partner’s state parameters. (See preceding table.)
Table 80: show lacp sysid - display description
Field Description
Channel group A link aggregation group configured on this switch.
System Priority
*
* The LACP system priority and system MAC address are concatenated to form the LAG system ID.
LACP system priority for this channel group.
System MAC
Address*
System MAC address.
Table 79: show lacp neighbors - display description (Continued)
Field Description
