Chapter 4
| Interface Configuration
Trunk Configuration
– 143 –
◆ Ports are only allowed to join the same Link Aggregation Group (LAG) if (1) the
LACP port system priority matches, (2) the LACP port admin key matches, and
(3) the LAG admin key matches (if configured). However, if the LAG admin key is
set, then the port admin key must be set to the same value for a port to be
allowed to join that group.
Note:
If the LACP admin key is not set when a channel group is formed (i.e., it has a
null value of 0), the operational value of this key is set to the same value as the port
admin key used by the interfaces that joined the group (see the “show lacp
internal” command described in the CLI Reference Guide).
Parameters
These parameters are displayed:
Configure Aggregator
◆ Admin Key – LACP administration key is used to identify a specific link
aggregation group (LAG) during local LACP setup on the switch.
(Range: 0-65535)
◆ Timeout Mode – The timeout to wait for the next LACP data unit (LACPDU):
■
Long Timeout – Specifies a slow timeout of 90 seconds. (This is the default
setting.)
■
Short Timeout – Specifies a fast timeout of 3 seconds.
The timeout is set in the LACP timeout bit of the Actor State field in transmitted
LACPDUs. When the partner switch receives an LACPDU set with a short
timeout from the actor switch, the partner adjusts the transmit LACPDU
interval to 1 second. When it receives an LACPDU set with a long timeout from
the actor, it adjusts the transmit LACPDU interval to 30 seconds.
If the actor does not receive an LACPDU from its partner before the configured
timeout expires, the partner port information will be deleted from the LACP
group.
When a dynamic port-channel member leaves a port-channel, the default
timeout value will be restored on that port.
When a dynamic port-channel is torn down, the configured timeout value will
be retained. When the dynamic port-channel is constructed again, that timeout
value will be used.
Configure Aggregation Port - General
◆ Port – Port identifier. (Range: 1-28/52)
◆ LACP Status – Enables or disables LACP on a port.
