Chapter 4
| Power and Grounding
How to Connect to DC Power
– 37 –
Warning:
If the power leads are plugged into the wrong holes, the power supply
will not work properly and may damage the switch.
6. Push each wire about half an inch into the opening on the plug, and tighten
down the clamp screw securely. You should not be able to pull on the wire and
dislodge it.
7. Insert the power plug in the power receptacle on the rear panel.
8. At the power source, turn on the power for the feed lines or power bus.
9. Check the the Power LED indicator as the switch is powered on. If the Power
LED is not on, recheck the power supply and power cable connections at the
supply source.
