Configuring the ECN330-switch
2291553-KDU 137 365 Uen D 2006-06-16
• VLAN – ID of configured VLAN (1-4094).
• Address Table Sort Key – Sorts the information displayed based on
MAC address, VLAN or interface (port or trunk).
• Dynamic Address Counts – The number of addresses dynamically
learned.
• Current Dynamic Address Table – Lists all the dynamic addresses.
Web – Click Address Table, Dynamic Addresses. Specify the search type (that
is, mark the Interface, MAC Address, or VLAN checkbox), select the method of
sorting the displayed addresses, and then click Query.
Figure 89 Dynamic Addresses
CLI – This example also displays the address table entries for port 1.
Console#show mac-address-table interface ethernet 1/1
Interface Mac Address Vlan Type
--------- ----------------- ---- -----------------
Eth 1/ 1 00-E0-29-94-34-DE 1 Permanent
Eth 1/ 1 00-20-9C-23-CD-60 2 Learned
Console#
