Configuring the ECN330-switch
2651553-KDU 137 365 Uen D 2006-06-16
CLI – This example enables EAPS globally on the ECN330-switch.
6.11.2 EAPS Domain Configuration
Use the EAPS Domain Configuration page to configure EAPS domains.
Command Usage
An EAPS domain containing one Control VLAN and one or more Protected
VLANs must be configured, and the EAPS function enabled on the ECN330-
switch (EAPS Configuration, section 6.11.1 on page 264) before a domain can
start running on the ring. Once enabled, the master node and transit node state
machines will start, and the domain will enter the active state.
To create an EAPS domain:
1. Enter a suitable name in the "Domain Name" field on the EAPS Domain
Configuration page, and click the New button.
2. Configure the EAPS domain parameters for this node, including the control
VLAN, the primary and secondary ports, the timers, EAPS node type, and
domain status.
3. Click the Modify Protected VLAN button, and add the data VLANs that will
be protected by the EAPS mechanism.
Command Attributes
New EAPS Domain
• Domain Name – Name of a specific EAPS domain. (Range: 1-32
characters)
EAPS Domain List
• Domain Name – Name of a configured EAPS domain.
• Bridge-Links – The number of Protected VLANs configured on the
EAPS domain.
Console(config)#eaps
Console(config)#
