1334 Matrix ETERNITY NE System Manual
Basic SE Commands
This section lists the Basic SE Commands required for configuring the important network parameters using a
telephone. However, it is highly recommended to configure the system using Jeeves, but in case you need to
configure any other parameter using a telephone, contact the Matrix Technical Support Team for assistance.
To assign IP Address to Ethernet Port 2110-IP Address
where,
IP Address is 15 digits maximum. 000 to 255 for the first 3 Octets
and 001 to 254 for the 4th Octet. Use zeros as fillers and dial the
digits in a continuous sequence. Do not dial ‘.’ in the IP Address.
For example: To assign the IP Address to 192.168.50.10 dial
2110-192168050010.
To assign Subnet Mask to Ethernet
Port
2111-Subnet Mask
For example: To assign the Subnet Mask to 255.255.255.0 dial
2111-255255255000.
To assign Gateway IP Address 2112-Gateway IP Address
where,
Gateway IP Address may be a maximum of 15 digits max. Follow
the same instructions as assigning IP Address to the Ethernet
Port.
To select Connection Type 2116-Connection Type
where,
Connection Type is
1 for Static
2 for DHCP
3 for PPPoE
Default: Static
To configure Web Server Port 2121-Port number
Port range is: 80, 1025 to 65535.
To view IP Address of Ethernet Port
2150
To view Subnet Mask of Ethernet Port
2151
To view Gateway Address of Ethernet
2152
To view Ethernet link Status
2162
To load the default parameters
5302
