226 Matrix ETERNITY NE System Manual
Configuring Open SIP Phones
You can connect any of the following as SIP Extensions of the SARVAM UCS:
• Matrix SPARSH VP248
47
• Matrix SPARSH VP110
• Matrix SPARSH VP710 - Standard SIP
• Any Standard third party Open SIP Phone
• Any SIP-enabled device including PC based Soft-phone
• Analog Phone Adapter
For detailed product information and operational instructions, refer to the product documentation supplied
with the Open SIP Phone/device.
SARVAM UCS supports two separate methods of Provisioning the Open SIP Phones. These two methods are:
• Manual Provisioning: In Manual Provisioning, the user must configure the required parameters of the
Open SIP Phone manually. So, it is not a simple plug-and-play solution for mass deployment, as it requires
intervention of authorized technical personnel for phone configuration. To configure Open SIP Phones
using this method, see “Configuring Open SIP Phones using Manual Provisioning”.
• Auto Provisioning: In Auto Provisioning, the Open SIP Phone gets configured automatically by retrieving
the required configuration file from the SARVAM UCS. The configuration file contains pre-programmed
values of necessary parameters required by the Open SIP Phone. Thus, it eliminates the necessity of
manually configuring the Open SIP Phone parameters. When the Open SIP Phone starts, it then gets
configured automatically. Here, SARVAM UCS acts as the Auto Provisioning Server by providing the
configuration file to the Open SIP Phones. Auto Provisioning enables mass deployment of Open SIP
Phones and provides a plug-and-play solution for them. To configure Open SIP Phones using this method,
see “Configuring Open SIP Phones using Auto Provisioning”.
• Auto Provisioning for Matrix SPARSH Phones and Third Party SIP Phones is supported only through
the HTTP Port.
• For Auto Provisioning, you must configure the Open SIP phones at Location1 only. You will have to
manually configure the Open SIP phones at Location 2 and 3.
• If you have already configured the phones at Location 2 and 3 and you upgrade the firmware, the
phones will not function as Auto Provisioning is not supported at these locations. You will have to
configure these phones again manually.
Configuring Open SIP Phones using Manual Provisioning
To be able to use Open SIP Phones/devices with SARVAM UCS, you must configure the following:
• Configure the SIP Extension General Parameters. For details, see “Configuring SIP Extension General
Parameters” in “SIP Extensions”.
48
47. Auto Provisioning is not supported in SPARSH VP248.
48. Some of the parameters may not be applicable depending on the Open SIP Phone you have connected to the SARVAM UCS.
