Matrix ETERNITY NE System Manual 147
• Select the Type of Jitter Buffer you want to use: Static or Dynamic. Default: Dynamic.
Static Jitter Buffer's internal delay is static, whereas, the Dynamic Jitter Buffer's internal delay adapts
itself to the jitter in the network.
• If you selected Static Jitter Buffer, configure Minimum Delay
33
, from 10 to 280 milliseconds. Default 10
milliseconds.
The value configured in the Minimum Delay determines the size of the Static Jitter buffer.
• If you selected Dynamic Jitter Buffer, configure Minimum Delay
34
and Optimization Factor, from 1 to
13. Default: 10. By default Minimum Delay is set to 10 milliseconds.
The Optimization Factor determines the rate of adaptation of the Dynamic Jitter Buffer to the jitter in the
network. The minimum size of the Dynamic Jitter buffer depends on the 'Minimum Delay' configured.
In networks with higher jitter, a higher value should be configured as Optimization Factor.
The actual size of the Dynamic Jitter Buffer will be determined by the DSP on the basis of the
Optimization Factor configured and actual network condition. Dynamic Jitter buffer can go up to
maximum 300 milliseconds.
• If you are using Fax over IP (FoIP)
35
, select the protocol as Fax Type. You may select:
• T.38 (UDPTL)
• T.38 (RTP)
• Pass-through.
Default: T.38 (UDPTL)
• 'Pass Through' and 'T.38' will work only if the peer devices also support the same option.
• If you select 'Pass through' as Fax type, you must disable 'Silence Suppression'.
• If the fax sent using T.38 is rejected, SARVAM UCS will use Pass Through for sending the Fax.
• If you have selected T.38 as Fax Type, configure T.38 Fax Parameters.
Receiving good quality Fax over IP depends on high 'Eye Quality Monitor' (EQM). The higher the Eye
Quality Monitor, the better the Fax quality. To improve the quality of T.38 fax reception, do the following:
• Configure the Fax Version as supported by the Remote Peer, which may be a Proxy Server or a SIP
Device. While sending a fax, the Version will be sent in the re-INVITE Message to the Remote Peer.
While receiving a fax SARVAM UCS will accept a Version equal to or less than the configured Version.
32. The speed at which voice packets travel through a network depends on the condition of the network. All voice packets may not
come at the same speed. This variation in the delay in receiving packets, known as Jitter, affects voice quality. Jitter Buffer helps
overcome the delay in receiving voice packets and improves voice quality. Jitter Buffer receives voice packets, stores them and
sends it to the DSP to process it at evenly spaced intervals, thus improving voice quality.
33. This parameter is to be configured for both Static and Dynamic Jitter Buffer. The Minimum Delay determines the size of the Static
Jitter Buffer and when Jitter Buffer type is Static, the Minimum Delay defines the size of the Static Jitter Buffer. 'Minimum Delay'
can be from 10 to 280 milliseconds. By default Minimum Delay is set to 10 milliseconds. The Static Jitter Buffer will store each
received voice packets for the configured time and then it will send it to DSP for voice processing.
34. When Jitter Buffer type is Dynamic, the Minimum Delay specifies the minimum time for which the Dynamic Jitter Buffer will store
the received voice packet before sending it to the DSP for voice processing.
35. You can send/receive Fax, by connecting a fax machine to the SLT port of SARVAM UCS.
