218 Matrix ETERNITY NE System Manual
• RTP Listening Port: This is the port on which the phone listens for RTP packets. This port is also used
as the source port for sending RTP packets to the remote peer. The valid range for this port is 1025-
65278. Default: 8000.
• Set the SIP Quality of Service (QoS) for SIP signaling as:
• SIP DiffServe/ToS: The system sends all the SIP signaling messages with this QoS setting. This field
defines the priority bits for SIP messages. The Valid DiffServe range is from 00-63, default: 26.
• Voice DiffServe/ToS: The system sends all the Voice packets with this QoS setting. This field defines
the priority bits for Voice packet. It also improves the voice quality.The Valid DiffServe range is from 00-
63, default: 46.
• Video DiffServe/ToS: The system sends all the Video packets with this QoS setting. This field defines
the priority bits for Video packet. It also improves the video quality.The Valid DiffServe range is from 00-
63, default: 46.
Configure any decimal value as per your requirement from the table mentioned below:
DSCP <=> IP Precedence Conversion Table
DSCP Name DS Field Binary Value Decimal IP Precedence
CS
0
000 000 0 0
CS
1
001 000 8 1
AF
11
001 010 10 1
AF
12
001 100 12 1
AF
13
001 110 14 1
CS
2
010 000 16 2
AF
21
010 010 18 2
AF
22
010 100 20 2
AF
23
010 110 22 2
CS
3
011 000 24 2
AF
31
011 010 26 3
AF
32
011 100 28 3
AF
33
011 110 30 3
CS
4
100 000 32 4
AF
41
100 010 34 4
AF
42
100 100 36 4
AF
43
100 110 38 4
CS
5
101 000 40 5
EF 101 110 46 5
CS
6
110 000 48 6
