Matrix ETERNITY NE System Manual 885
Key Label Item Description
1 Power Indicator LED
Indicates the status of calls, messages and voicemails.
Also displays the registration status of the IP Phone.
2 Touch Screen
7 inch (1024 x 600) capacitive (5 point) touch screen. Tap to
select and highlight screen items.
3 Headset Key
Toggles and indicates the headset mode. The key LED
illuminates solid green when you activate the headset mode.
4
Mute Key
Toggles and indicates mute feature. The key LED illuminates
solid red when you mute a call.
5
Call Log Key
Displays all the missed, received and dialed calls.
6
Speaker Key
Toggles and indicates the speaker mode. The key LED
illuminates solid green when you activate the speaker mode.
7
Transfer Key Transfers a call to another party.
8
Hold Key Places a call on hold or resumes a held call.
9
Voicemail Key
Accesses voice mails.
10
Volume Key
Adjusts the volume of the handset, headset, speaker, ringer or
media.
11
Keypad Provides the digits and special characters.
12
Speaker
Provides speaker audio output.
13
Hookswitch Tab
Secures the handset in the handset cradle when the IP Phone
is mounted vertically.
14
Hookswitch
Picking up the handset from the handset cradle, the hookswitch
bounces and the phone connects to the line.
Laying the handset down on the handset cradle, the phone
disconnects from the line.
15
Camera Lens
2 Mega-pixel camera. Provides near-site video. The better
distance between camera and images you want to capture
should be in the range of 0.35 meters (1 foot) to 2 meters (6
feet).
16
Camera Indicator LED Indicates the status of camera and video calls.
17
Shutter Switch
Covers and uncovers the camera. When the camera is
switched off, the video image is black.
18
USB2.0 Port
Allows you to connect the USB flash drive/USB headset to the
phone.
