Port Integration Module (S12GPIMV1)
MC9S12G Family Reference Manual Rev.1.27
NXP Semiconductors 179
T 0x0240 PTT—Port T Data Register R/W 0x00 2.4.3.15/2-207
0x0241 PTIT—Port T Input Register R
3
2.4.3.16/2-207
0x0242 DDRT—Port T Data Direction Register R/W 0x00 2.4.3.17/2-208
0x0243 Reserved R 0x00
0x0244 PERT—Port T Pull Device Enable Register R/W 0x00 2.4.3.18/2-209
0x0245 PPST—Port T Polarity Select Register R/W 0x00 2.4.3.19/2-210
0x0246 Reserved R 0x00
0x0247 Reserved R 0x00
S 0x0248 PTS—Port S Data Register R/W 0x00 2.4.3.20/2-210
0x0249 PTIS—Port S Input Register R
3
2.4.3.21/2-211
0x024A DDRS—Port S Data Direction Register R/W 0x00 2.4.3.22/2-211
0x024B Reserved R 0x00
0x024C PERS—Port S Pull Device Enable Register R/W 0xFF 2.4.3.23/2-212
0x024D PPSS—Port S Polarity Select Register R/W 0x00 2.4.3.24/2-212
0x024E WOMS—Port S Wired-Or Mode Register R/W 0x00 2.4.3.25/2-213
0x024F PRR0—Pin Routing Register 0
4
R/W 0x00 2.4.3.26/2-213
M 0x0250 PTM—Port M Data Register R/W 0x00 2.4.3.27/2-215
0x0251 PTIM—Port M Input Register R
3
2.4.3.29/2-216
0x0252 DDRM—Port M Data Direction Register R/W 0x00 2.4.3.29/2-216
0x0253 Reserved R 0x00
0x0254 PERM—Port M Pull Device Enable Register R/W 0x00 2.4.3.30/2-217
0x0255 PPSM—Port M Polarity Select Register R/W 0x00 2.4.3.31/2-218
0x0256 WOMM—Port M Wired-Or Mode Register R/W 0x00 2.4.3.32/2-218
0x0257 PKGCR—Package Code Register R/W
5
2.4.3.33/2-219
P 0x0258 PTP—Port P Data Register R/W 0x00 2.4.3.34/2-220
0x0259 PTIP—Port P Input Register R
3
2.4.3.35/2-221
0x025A DDRP—Port P Data Direction Register R/W 0x00 2.4.3.36/2-222
0x025B Reserved R 0x00
0x025C PERP—Port P Pull Device Enable Register R/W 0x00 2.4.3.37/2-222
0x025D PPSP—Port P Polarity Select Register R/W 0x00 2.4.3.38/2-223
0x025E PIEP—Port P Interrupt Enable Register R/W 0x00 2.4.3.39/2-224
0x025F PIFP—Port P Interrupt Flag Register R/W 0x00 2.4.3.40/2-224
Table 2-18. Block Memory Map (0x0000-0x027F) (continued)
Port
Global
Address
Register Access Reset Value Section/Page
To Next Page
