Parameter List
11
11.9 H: TERMINALS
SIEPCYEUOQ2V01A Q2V Technical Manual 357
Setting Value Function Description Ref.
1D RunCmdSource
Shows the selected Run command source.
ON : The keypad is the Run command source.
OFF : Parameter b1-02 or b1-16 [Run Comm. Sel 1 or Run Comm. Sel 2] is the Run command source.
603
1E Motor2 Select
The terminal activates when motor 2 is selected.
ON : Motor 2 Selection
OFF : Motor 1 Selection
603
1F Restart Enable
The terminal activates when the Auto Restart function is trying to restart after a fault.
603
20 FltReset Active
The terminal turns on when the drive receives the Reset command from the control circuit terminal, serial
communications, or the communication option.
603
21 PolePos Detection
The terminal activates when drive receives a Run command and the drive detects the motor magnetic pole position
of the PM motor.
603
22 Ext 24V Supply
The terminal activates when there is an external 24V power supply between terminals E24V-A0V.
ON : An external 24V power supply supplies power.
OFF : An external 24V power supply does not supply power.
603
2F @SpeedSearch
The terminal activates when the drive is doing speed search.
603
30 During Torque Limit
The terminal activates when the torque reference is the torque limit set with L7 parameters or H3-02 or H3-10
[MFAI Function Select].
604
32 TrqDetect1NO
The terminal activates when the drive detects overtorque or undertorque.
ON : The output current/torque is more than the torque value set with L6-02 [Trq Det1 Level], or the level is less
than the torque value set with L6-02 for longer than the time set with L6-03 [Trq Det1 Time].
604
33 TrqDetect1NC
The terminal deactivates when the drive detects overtorque or undertorque.
OFF : The output current/torque is more than the torque value set with L6-02 [Trq Det1 Level], or the level is less
than the torque value set with L6-02 for longer than the time set with L6-03 [Trq Det1 Time].
604
37 TrqDetect2NO
The terminal activates when the drive detects overtorque or undertorque.
ON : The output current/torque is more than the torque value set with L6-05 [Trq Det2 Level], or the level is less
than the torque value set with L6-05 for longer than the time set with L6-06 [Trq Det2 Time].
604
38 TrqDetect2NC
The terminal deactivates when the drive detects overtorque or undertorque.
OFF : The output current/torque is more than the torque value set with L6-05 [Torque Detection Level 2], or the
level is less than the torque value set with L6-05 [Torque Detection Level 2] for longer than the time set with L6-06
[Torque Detection Time 2].
604
39 Timer Output
Use this setting when the drive uses the timer function as an output terminal.
605
3C Comparator 1
The terminal activates if the monitor value set with H2-20 [Compare1 Mon.Selection] is in range of the values of
H2-21 [Compare1 Low Limit] and H2-22 [Compare1 Up Limit] for the time set in H2-24 [Compare1 On-Delay
Time].
605
3D Comparator 2
The terminal activates if the monitor value set with H2-26 [Compare2 Mon.Selection] is not in the range of the
values of H2-27 [Compare2 Low Limit] and H2-28 [Compare2 Up Limit] for the time set in H2-30 [Compare2
On-Delay Time].
605
3E PID Fbk Low
The terminal activates when the drive detects FbL [PID Feedback Loss].
606
3F PID Fbk High
The terminal activates when the drive detects FbH [Excessive PID Feedback].
606
4A DC Bus Undervolt
The terminal activates when the DC bus voltage or control circuit power supply is less than the voltage set with
L2-05 [UV Detection Lvl (Uv1)]. The terminal also turns on when there is a fault with the DC bus voltage.
ON : The DC bus voltage is less than the setting value of L2-05.
OFF : The DC bus voltage is more than the setting value of L2-05.
606
4B FreqRef Loss
The terminal activates when the drive detects a loss of frequency reference.
606
4C BrkRes Fault
The terminal activates when the mounting-type braking resistor is overheating or when there is a braking transistor
fault.
606
