Oracle ZFS Storage Appliance

Network Icons
* Disabled icons are shown at left.
The following icons are used to distinguish different types of objects and provide information of
secondary importance.
TABLE 4
Miscellaneous Icons
Icon Description Icon Description
allow SAS
deny SAS port
storage pool
Network Icons
These icons indicate the state of network devices and type of network datalinks:
TABLE 5
Network Icons
Icon Description Icon Description
active network device active Infiniband port
inactive network device inactive Infiniband port
network datalink network datalink (IB
partition)
network datalink VLAN
network datalink
aggregation
network datalink
aggregation VLAN
Dashboard Icons
The following icons indicate the current state of monitored statistics with respect to user-
configurable thresholds set from within Settings.
30 Oracle ZFS Storage Appliance Administration Guide, Release OS8.6.x • September 2016
