Page #59 background image
Configuring Management Interfaces (BUI)
Configuring Management Interfaces (BUI)
Use the following procedure to configure management interfaces.
1.
Go to Configuration > Network.
2.
Click the add icon next to Datalinks.
3.
Set the following minimum datalink properties and click APPLY.
VNIC - Select this check box.
Name - Type a name for the datalink.
4.
Drag the resulting datalink to the Interfaces column.
5.
In the Network Interface dialog box, set the following minimum interface
properties and click APPLY:
Name - Type a name for interface.
Enable Interface - Select this check box to enable the interface.
Allow Administration - Select this check box to make this a management interface, which
enables BUI connections on port 215 and CLI connections on ssh port 22.
Note - The Allow Administration option makes it a management interface, enabling BUI
connections on port 215 and CLI connections on ssh port 22.
Use IPv4 Protocol or Use IPv6 Protocol - Select a protocol, its type of address, and enter
one or more IP addresses in CIDR notation.
6.
If clustered controllers, repeat steps 1-5 on the second controller.
7.
Click the trash icon next to Untitled Interface, which is the default interface, to
destroy it.
Note - When an interface is deleted, all routes associated with the interface are also removed.
8.
In the Update Default Route dialog box, type the Default Gateway and select an
Interface from the drop-down menu. Click COMMIT WITH ROUTE.
The default gateway is the default router IP address. For the interface, select the datalink that
you assigned to the first management interface.
Configuring the Appliance 59
