Parameter Description
l curSet
Only the data set of the current selected data set will restore
Restore Type Available only when RecipeDataSet=AllRecipeDataSet.
This parameter define the behavior when the numbers of data sets inside the file to restore is not
matching with the data set number inside the HMI device
l Replace
All data sets that are inside the device are removed and replaced with the data sets from the
csv file
l Match
Replace only the data set inside the device that have the same data set id
l MatchAndAdd
Replace the data set inside the device that have the same data set id and add the additional
data set found inside the csv file (Note: data sets that are inside the device but not inside the
csv file are not removed from the device)
FilePath Source folder
l Internal = \Flash\QTHMI\workspace\Dump
l USB drive = \USBMemory
l SDCard = \Storage Card
l Public Network = \\<hostname or IP>\sharePath
l Private Network = \\<username>:<password>@<hostname or IP>\sharePath
Note: supported formats for external memory are FAT or FAT32 (NTFS format is not
supported).
Note: Private networks are supported only from Linux devices with BSP 1.0.25 and above.
FileName Attached tag from which read the file name at run time.
BrowseForFile true = shows the Open dialog to browse the file to read.
false = no dialog is shown,
AddRecipeDataSet
Adds a new dataset to the selected recipe. The new dataset is appended at the end of the already defined datasets.
132
HMWIN Studio |User Manual|v206 (2017-06-30) |EN|© 2014-2017 Panasonic Electric Works Europe AG
Recipe actions
